Portable Scale For Front-End Loaders
 ✖  |
"It fits any tractor loader that lifts hydraulically and accurately weighs whatever you put in the bucket," says T.J. Shambaugh, Jr., developer of the new easy-to-use, do-it-yourself weighmaster. It consists of a gauge that measures the amount of hydraulic pressure needed to hold the loaded bucket at a certain height. The pressure reading is calibrated to pounds by a formula which Shambaugh provides.
To install, you tee into the hydraulic line between the valve and the lift cylinder and install the hose that runs to the gauge. You then raise the loader with the bucket empty and set the gauge at zero. By adding predetermined weights, you calibrate the gauge which Shambaugh says is accurate to within .5%.
weight of the load with the bucket at the same height each time and with the tractor on fairly level ground.
The gauge used depends on the tractor's hydraulic system. Besides a gauge, you'll need hydraulic hose and a mounting bracket.
Shambaugh's plans are available for $25 and include installation instructions, calibration formula, parts lists and places to buy the needed equipment. He estimates equipment costs at less than $250.
For more information, contact: FARM SHOW Followup, T.J. Shambaugh, Jr., Rt. 1, Box 79A, Oakley, Ill. 62552 (ph 217 763-5651).
